With over a decade of experience, NEP excels in advanced energy conversion solutions for residential, commercial, and industrial sectors worldwide.
Our track record boasts 500,000+ top-tier microinverters and fast shutdown MLPE products supplied to customers in 35+ countries.
Globally certified to C-ETL-us, SAA, TUV, VDE-AR-N 4105, VDE 0126, G83 / 2, CEI 021, IEC61727, EN50438 Protection class IP66, IP67, NEMA 6 high efficiency with 95.5% maximum.
Simple and practical design
Dimensions: 7.09'' x 7.32'' x 0.98'' weight of 3.3 lbs,
Operating temperature of -40°F to +185°F. Natural
convection cooling system.
Very simple installation with built-in cables and connectors. Integrated monitoring and power line communication with integrated BDG-256 GFDI gateway. Integrated ground connection for easy installation.
| Battery Type | BDH-5KS：Li-Ion BDH-10KS：Li-Ion BDH-10KT-AS： |
| Battery Voltage Range | BDH-5KS：85~450V BDH-10KS：85~450V BDH-10KT-AS：180~600V |
| Rated Charging Current | BDH-5KS：50A BDH-10KS：50A BDH-10KT-AS：30A |
| Rated Discharging Current | BDH-5KS：50A BDH-10KS：50A BDH-10KT-AS：30A |
| Rated Charging Power | BDH-5KS：5kW BDH-10KS：10kW BDH-10KT-AS：10kW |
| Rated Discharging Power | BDH-5KS：5kW BDH-10KS：10kW BDH-10KT-AS：10kW |
| Rated Output Power | BDH-5KS：5kW BDH-10KS：10kW BDH-10KT-AS：10kW |
| Rated AC Current @230Vac | BDH-5KS：21.7A BDH-10KS：43.5A BDH-10KT-AS：14.5A |
| Rated AC Voltage | BDH-5KS：L/N/PE,220V/230V BDH-10KS：L/N/PE,220V/230V BDH-10KT-AS：3L/N/PE,380V/400V |
| Rated Output Frequency | 50Hz/60Hz±5 |
| Power Factor[cosφ] | 0.8 leading~0.8 lagging |
| Total Harmonic Distortion[THDi] | ＜3% |
| Rated Output Power | BDH-5KS：5kW BDH-10KS：10kW BDH-10KT-AS：10kW |
| Peak Output Apparent Power | BDH-5KS：10kVA BDH-10KS：20kVA BDH-10KT-AS：16.5kVA,60s |
| Rated Output Current @230Vac | BDH-5KS：21.7A BDH-10KS：43.5A BDH-10KT-AS：14.5A |
| Rated Output Voltage | BDH-5KS：L/N/PE,220V/230V BDH-10KS：L/N/PE,220V/230V BDH-10KT-AS：3L/N/PE,380V/400V |
| Rated Output Frequency | 50Hz/60Hz±5 |
| Output THDv (@Linear Load) | ＜3% |
| Max. Efficiency | BDH-5KS：98.00% BDH-10KS：98.00% BDH-10KT-AS：98.30% |
| European Efficiency | BDH-5KS：97.50% BDH-10KS：97.50% BDH-10KT-AS：97.65% |
| Max. Battery Charging/ Discharging Efficiency | BDH-5KS：97.00% BDH-10KS：97.00% BDH-10KT-AS：97.60% |
| Residual Current Monitoring | Integrated |
| AC Overcurrent Protection | Integrated |
| AC Overvoltage Protection | Integrated |
| Anti-islanding Protection | Integrated |
| Battery Switch | Integrated |
| AC Surge Protection | Type II |
| Topology | Non-isolated |
| Operating Temperature Range | -40℃~+60℃(45℃~60℃，with derating) |
| Relative Humidity | 0%~100%non-condensing |
| Max. Operating Altitude | 4000m（>3000mpower derating） |
| Display | LED+APP |
| Communication Port | CAN/RS485/DRM |
| Communication | BDH-5KS：WIFI BDH-10KS：WIFI BDH-10KT-AS：WIFI/4G(Optional) |
| Cooling Method | Natural convection |
| Weight | BDH-5KS：18.5kg BDH-10KS：18.5kg BDH-10KT-AS：22.5kg |
| Dimension(H*W*D) | BDH-5KS：620*440*210mm BDH-10KS：620*440*210mm BDH-10KT-AS：455*440*206mm |
| Ingress Protection Rating | IP65 |
| Mounting Method | Wall Mounted |
