With over a decade of experience, NEP excels in advanced energy conversion solutions for residential, commercial, and industrial sectors worldwide.
Our track record boasts 500,000+ top-tier microinverters and fast shutdown MLPE products supplied to customers in 35+ countries.
Globally certified to C-ETL-us, SAA, TUV, VDE-AR-N 4105, VDE 0126, G83 / 2, CEI 021, IEC61727, EN50438 Protection class IP66, IP67, NEMA 6 high efficiency with 95.5% maximum.
Simple and practical design
Dimensions: 7.09'' x 7.32'' x 0.98'' weight of 3.3 lbs,
Operating temperature of -40°F to +185°F. Natural
convection cooling system.
Very simple installation with built-in cables and connectors. Integrated monitoring and power line communication with integrated BDG-256 GFDI gateway. Integrated ground connection for easy installation.
| Maximum Utilized Solar Power | BDH-8KSP-LB：12000W BDH-10KSP-LB：15000W BDH-12KSP-LB：18000W |
| Rated PV Input Voltage | 360V |
| PV Input Voltage Range | 100~600V |
| MPPT Operating Voltage Range | 120~500V |
| Start-up Voltage | 140V |
| No. of MPP Trackers | BDH-8KSP-LB：2 BDH-10KSP-LB：2 BDH-12KSP-LB：3 |
| No. of Strings per MPPT | BDH-8KSP-LB：1/1 BDH-10KSP-LB：1/1 BDH-12KSP-LB：2/1/1 |
| Max. Input Current per MPPT | BDH-8KSP-LB：25A/25A BDH-10KSP-LB：25A/25A BDH-12KSP-LB：25A/15A/15A |
| Max. Short Circuit Current per MPPT | BDH-8KSP-LB：31A/31A BDH-10KSP-LB：31A/31A BDH-12KSP-LB：31A/19A/19A |
| Battery Type | Lithium-ion/Lead-Acid |
| Rated Battery Voltage | 48V |
| Battery Voltage Range | 40~60V |
| Max. Charging/Discharging current | BDH-8KSP-LB：167A BDH-10KSP-LB：210A BDH-12KSP-LB：250A |
| Max. Charging/Discharging power | BDH-8KSP-LB：8000W BDH-10KSP-LB：10000W BDH-12KSP-LB：12000W |
| Force wake up battery from PV function | YES |
| Rated AC Voltage | 120V/240V;120V/208V |
| Rated AC Frequency | 50Hz/60Hz |
| Rated AC Output Current | BDH-8KSP-LB：33.3A@240V/38.5A@208V BDH-10KSP-LB：41.6A@240V/48A@208V BDH-12KSP-LB：50A |
| Rated AC Output Power | BDH-8KSP-LB：8000W BDH-10KSP-LB：10000W BDH-12KSP-LB：12000W |
| Max. AC Intput Current | 200A |
| Max. AC Intput Power | 48000W |
| PF | 0.99(Adjustable from 0.9 leading to0.9 lagging) |
| THDi | ＜3% |
| AC Bypass (Grid) | 200A |
| Rated Output Voltage | 120V/240V;120V/208V;240V |
| Rated Output Frequency | 50Hz/60Hz |
| Rated Output Current | BDH-8KSP-LB：33.3A@240V/38.5A@208V BDH-10KSP-LB：41.6A@240V/48A@208V BDH-12KSP-LB：50A |
| Rated Output Power | BDH-8KSP-LB：8000W BDH-10KSP-LB：10000W BDH-12KSP-LB：12kW@240V/10.4kW@208V |
| Peak Power | BDH-8KSP-LB： With PV: 8.8kW (2h),9.6kW (15 min), 10.4kW (7.5 min), 13.2kW (750ms) Without PV: 8.8kW (10 min) BDH-10KSP-LB： With PV: 11kW (2h),12kW (15 min), 13kW (7.5 min), 16.6kW (750ms) Without PV: 11kW (10 min) BDH-12KSP-LB： With PV: 13.2kW (2h),14.4kW (15 min), 15.6kW (7.5 min), 20kW (750ms) Without PV: 13.2kW (10 min) |
| Switching Time | 15ms |
| THDv | ＜3% |
| AC Bypass (Generator) | 90A |
| Max. MPPT Efficiency | 99.9% |
| Max. Efficiency | 97.5% |
| Max. Battery Charging/ Discharging Efficiency | 94.5% |
| CEC Efficiency | 96.5% |
| PV Reverse Polarity Protection | YES |
| Over Current/Voltage Protection | YES |
| Anti-islanding Protection | YES |
| AC Short-circuit Protection | YES |
| Ground fault monitoring | YES |
| Leakage Current Protecion | YES |
| AC/DC Surge Protection Type II | YES |
| AFCI | YES |
| RSD | YES |
| DC Switch | YES |
| Load Switch(Current) | 200A |
| Battery Switch(Current/Voltage) | 2*200A/80VDC |
| Dimensions(W*H*D) | 500*860*290mm/19.68*33.86*11.42inch |
| Weight | 52kg/121.2Ibs |
| Ingress Protection Rating | NAME 4X |
| Relative Humidity | 0~100% |
| Operating Temperature Range | 25~60℃, >45℃ derating |
| Storage Temperature Range | -25~60℃ |
| Communication Interface | RS485/CAN/Wi-Fi |
| Display | Color Touch LCD |
| Cooling Method | Smart Cooling |
| Topology | Transformer-less |
| Altitude | <2000m |
| Warranty | 10years |
| UL STD.1741,1741SA,1741SB | IEEE STD.1547,1547.1,1547a HECO SRD-IEEE-1547.1:2020 Ed.2.0 |
| CSA STD.C22.2 No.107.1 and 330 | UL1998:2018; 2030.5 E5000,SA17-18; PCS CRD:2019 |
