With over a decade of experience, NEP excels in advanced energy conversion solutions for residential, commercial, and industrial sectors worldwide.
Our track record boasts 500,000+ top-tier microinverters and fast shutdown MLPE products supplied to customers in 35+ countries.
Globally certified to C-ETL-us, SAA, TUV, VDE-AR-N 4105, VDE 0126, G83 / 2, CEI 021, IEC61727, EN50438 Protection class IP66, IP67, NEMA 6 high efficiency with 95.5% maximum.
Simple and practical design
Dimensions: 7.09'' x 7.32'' x 0.98'' weight of 3.3 lbs,
Operating temperature of -40°F to +185°F. Natural
convection cooling system.
Very simple installation with built-in cables and connectors. Integrated monitoring and power line communication with integrated BDG-256 GFDI gateway. Integrated ground connection for easy installation.
| Battery Type | Li-Ion |
| Battery Voltage Range /V | 180~600 |
| Rated Charging Current /A | 30 |
| Rated Discharging Current /A | 30 |
| Rated Charging Power /kW | BDH-5KT：5 BDH-6KT：6 BDH-8KT：8 BDH-10KT：10 |
| Rated Discharging Power | BDH-5KT：5 BDH-6KT：6 BDH-8KT：8 BDH-10KT：10 |
| Max. Input Power | BDH-5KT：7.5 BDH-6KT：9 BDH-8KT：12 BDH-10KT：15 |
| Max. Input Voltage | 1000 |
| MPPT Operating Voltage Range | 180~900 |
| Start-up Voltage /V | 180 |
| Rated Input Voltage /V | 600 |
| Max. Input Current per MPPT /A | 15 |
| Max. Short Circuit Current per MPPT /A | 18 |
| No. of MPP Trackers | 2 |
| No. of Strings per MPPT | 1 |
| Rated Output Power /kW | BDH-5KT：5 BDH-6KT：6 BDH-8KT：8 BDH-10KT：10 |
| Max. Apparent Power /kVA | BDH-5KT：5.5 BDH-6KT：6.6 BDH-8KT：8.8 BDH-10KT：11 |
| Rated AC Current @230Vac /A | BDH-5KT：7.2 BDH-6KT：8.7 BDH-8KT：11.6 BDH-10KT：14.5 |
| Max. AC Current /A | BDH-5KT：8.3 BDH-6KT：10 BDH-8KT：13.3 BDH-10KT：16.7 |
| Rated AC Voltage | 3L/N/PE,380V/400V |
| Rated Output Frequency | 50Hz/60Hz±5 |
| Power Factor[cosφ] | 0.8 leading~0.8 lagging |
| Total Harmonic Distortion[THDi] | ＜3% |
| Rated Output Power /kW | BDH-5KT：5 BDH-6KT：6 BDH-8KT：8 BDH-10KT：10 |
| Peak Output Apparent Power /kVA,s | BDH-5KT：10, 60 BDH-6KT：12, 60 BDH-8KT：16, 60 BDH-10KT：16.5, 60 |
| Max. Output Current /A | BDH-5KT：8.0 BDH-6KT：9.6 BDH-8KT：12.8 BDH-10KT：15.9 |
| Rated Output Voltage | 3L/N/PE,380V/400V |
| Rated Output Frequency | 50Hz/60Hz±5 |
| Output THDv (@Linear Load) | ＜3% |
| Max. Efficiency | 98.30% |
| European Efficiency | 97.65% |
| Max. Battery Charging/ Discharging Efficiency | 97.60% |
| PV Insulation Resistance Detection | Integrated |
| Residual Current Monitoring | Integrated |
| AC Overcurrent Protection | Integrated |
| AC Overvoltage Protection | Integrated |
| Input Reverse Protection | Integrated |
| Anti-islanding Protection | Integrated |
| DC Switch | Integrated |
| AC Surge Protection | Type II |
| DC Surge Protection | Type II |
| AFCI | Optional |
| Topology | Non-isolated |
| Operating Temperature Range | -40~+60 (45~60 with derating) |
| Relative Humidity | 0%~100% non-condensing |
| Max. Operating Altitude | 4000m（>3000m power derating） |
| Display | LED+APP |
| Communication Port | CAN/RS485/RS232/DRM |
| Communication | WIFI/4G(Optional) |
| Cooling Method | Natural convection |
| Noise /dB | ＜30 |
| Weight /kg | 22.5 |
| Dimension(H*W*D) /mm | 455*440*206 |
| Ingress Protection Rating | IP65 |
| Mounting Method | Wall Mounted |
