With over a decade of experience, NEP excels in advanced energy conversion solutions for residential, commercial, and industrial sectors worldwide.
Our track record boasts 500,000+ top-tier microinverters and fast shutdown MLPE products supplied to customers in 35+ countries.
Globally certified to C-ETL-us, SAA, TUV, VDE-AR-N 4105, VDE 0126, G83 / 2, CEI 021, IEC61727, EN50438 Protection class IP66, IP67, NEMA 6 high efficiency with 95.5% maximum.
Simple and practical design
Dimensions: 7.09'' x 7.32'' x 0.98'' weight of 3.3 lbs,
Operating temperature of -40°F to +185°F. Natural
convection cooling system.
Very simple installation with built-in cables and connectors. Integrated monitoring and power line communication with integrated BDG-256 GFDI gateway. Integrated ground connection for easy installation.
| Battery Type | Lithium Iron Phosphate |
| Battery voltage range | 40~60V |
| Maximum continuous discharge current | 37.5A |
| Maximum continuous charging current | 37.5A |
| Maximum charging power | 2.5kW |
| Maximum discharge power | 2.5kW |
| Maximum input power | 600W×4 |
| Maximum input voltage | 60V |
| MPPT voltage range | 22V~55V |
| Starting voltage | 22V |
| Maximum input current of each MPPT | 20A |
| Maximum short-circuit current of each MPPT | 25A |
| MPPT quantity | 4 |
| Rated output power | 2kW |
| Peak apparent power | 2kW 20s |
| Maximum continuous current | 8.69A |
| Rated output voltage | L/N/PE,230V |
| Rated output frequency | 50Hz/60Hz |
| THD | <5% |
| Power Factor | -0.8 ~ 0.8 |
| Rated output power | 2kW |
| Peak apparent power | 2.4kW 20s |
| Maximum continuous current | 8.69A |
| Rated output voltage | L/N/PE,230V |
| Rated output frequency | 50Hz/60Hz |
| THD | <5% |
| Power Factor | -0.8 ~ 0.8 |
| Rated input power (AC+MPPT) | 2.5kW |
| Rated AC charging power | 2kW |
| Rated MPPT charging power | 2kW |
