With over a decade of experience, NEP excels in advanced energy conversion solutions for residential, commercial, and industrial sectors worldwide.
Our track record boasts 500,000+ top-tier microinverters and fast shutdown MLPE products supplied to customers in 35+ countries.
Globally certified to C-ETL-us, SAA, TUV, VDE-AR-N 4105, VDE 0126, G83 / 2, CEI 021, IEC61727, EN50438 Protection class IP66, IP67, NEMA 6 high efficiency with 95.5% maximum.
Simple and practical design
Dimensions: 7.09'' x 7.32'' x 0.98'' weight of 3.3 lbs,
Operating temperature of -40°F to +185°F. Natural
convection cooling system.
Very simple installation with built-in cables and connectors. Integrated monitoring and power line communication with integrated BDG-256 GFDI gateway. Integrated ground connection for easy installation.
| Recommended PV module maximum power /W | BDM-1200-LV：600 x 2 BDM-1600-LV：600 x 4 |
| PV Input Voltage Range /V | 20-60 |
| MPPT Operating Voltage Range /V | 22-55 |
| Start-up Voltage /V | 25 |
| No. of inputs | BDM-1200-LV：3 BDM-1600-LV：4 |
| Max PV current | BDM-1200-LV：25A×3 BDM-1600-LV：25A×4 |
| Rated AC Voltage /V | 120 |
| Rated AC Frequency | 50Hz/60Hz |
| Rated AC Output Current /A | 10 |
| Rated AC Output Power /W | 1200 |
| PF | >0.99(Adjustable from 0.9 leading to 0.9 lagging) |
| THDi | <5% |
| Max. MPPT Efficiency | 99.9% |
| Max. Efficiency | 97.5% |
| CEC Efficiency | 96.5% |
| PV Reverse Polarity Protection | YES |
| Over Current/Voltage Protection | YES |
| Anti-islanding Protection | YES |
| AC Short-circuit Protection | YES |
| Ground fault monitoring | YES |
| Leakage Current Protecion | YES |
| AC/DC Surge Protection Type II | YES |
| RSD | YES |
| Dimensions(W*H*D) | 321mm*271mm*42.5mm |
| Weight | 3.1kg |
| Ingress Protection Rating | NAME 4X |
| Relative Humidity | 0~100% |
| Operating Temperature Range | -40~65℃ |
| Storage Temperature Range | -40~85℃ |
| Communication Interface | PLC/WI-FI |
| Display | LED LIGHT |
| Altitude | <2000m |
| UL STD.1741,1741SA,1741SB | BDM-1200-LV：IEEE STD.1547,1547.1,1547a BDM-1600-LV：HECO SRD-IEEE-1547.1:2020 Ed.2.0 |
| CSA STD.C22.2 No.107.1 and 330 | BDM-1200-LV：IEEE 2030.5 BDM-1600-LV： E5000,SA17-18; PCS CRD:2019 |
